A median fin derived from the lateral plate mesoderm and the origin of paired fins

Two alternate hypotheses have been proposed to explain the evolutionary origin of vertebrate paired appendages (fins and limbs). Derivation from posterior gill arches was posited by Gegenbaur3, whilst a number of anatomists later invoked a rival theory, the lateral fin fold hypothesis. This proposed that paired fins derived (either phylogenetically or ontogenetically) from longitudinal bilateral fin folds that were then subdivided4,5. Whilst recent molecular studies have provided some evidence in support of each hypothesis2,6,7, there remains significant criticism of the lack of substantiation in the fossil record or in embryology1,8. Certain stem vertebrates, including anaspid-related fossils, show evidence of lateral fin folds; however, these fin folds mostly consist of soft tissue with only sporadic skeletal elements and are thus poorly preserved. This has led to conflicting interpretations9,10,11,12,13. The developmental programme for paired fins has been postulated to have been first assembled in median fins, which appear in the fossil record before the origin of paired fins2. A number of studies have traced the cellular origin of median fins in lamprey, catshark, zebrafish and Xenopus2,14,15. All median fins, both larval and adult, assessed so far have shown derivation from the paraxial mesoderm (PM), whilst paired fins are known to be derived from the lateral plate mesoderm (LPM). Thus, the median fin programme was most likely transferred to the LPM from the PM2, possibly before the formation of hypothesized lateral fin folds. How or when this transition occurred is unclear. As only a subset of median fins in zebrafish has been assayed, we expanded the characterization of the composition and origin of median fins in zebrafish to determine if PM derivation was an invariant characteristic.

As with most surveyed jawed vertebrates (gnathostomes), larval zebrafish possess two median unpaired fin folds. A caudal fin fold (or major lobe) runs continuously from the dorsal midline around the caudal end of the larva and then ventrally to the anus (Fig. 1a). A pre-anal fin fold (PAFF; or minor lobe) runs along the underside of the yolk sac extension, immediately anterior to the anus16 (Fig. 1a). The median fin folds are resorbed during metamorphosis, and the caudal fin fold is replaced by three separate PM-derived median adult fins14,17: the caudal fin, the dorsal fin and the anal fin. No adult median fin replaces the PAFF, which is a developmentally transient structure16. The mesenchyme of the caudal fin fold can be labelled by the photoconvertible Kaede green-to-red fluorescent protein expressed under control of the tbx16l promoter, confirming that this median fin is derived from the PM18. In contrast, we consistently failed to observe any Kaede labelling in the PAFF (Fig. 1b and Extended Data Fig. 1a). This labelling difference is not due to de novo activity of the tbx16l promoter specifically in the caudal median fin fold, as we photoconverted Kaede in anterior somites above the PAFF at 24 h post-fertilization (hpf) and traced the photoconverted Kaede to the mesenchyme of the dorsal portion of the caudal fin fold; again, we never found labelled cells in the PAFF (n = 11) (Extended Data Fig. 1b–d). The absence of PAFF labelling by a PM-lineage trace is not due to absence of mesenchyme cells, as we observed an abundance of these cells by Nomarski optics at 3 days post-fertilization (dpf) and in the enhancer trap line Et(krt4:EGFP)sqet37 (ET37), which labels all fin mesenchyme cells (Extended Data Fig. 1e,f). The ET37 line further allowed us to visualize the morphology of the mesenchyme cells, which showed a distally polarized stellate shape, indistinguishable from the mesenchyme of all other fins (Fig. 1c–e and Extended Data Fig. 1f–h). PAFF mesenchymal cells expressed known differentiation markers of fin mesenchyme, including fibulin1 (fbln1) and integrin beta 3b (itgb3b), and were weakly positive for lyve1b reporter activity in the lyve1b:DsRed2 transgenic line, which also expresses in the post-anal ventral fin mesenchyme19 (Fig. 1f–h and Extended Data Fig. 1i). Hence, despite their divergent developmental origin, PAFF mesenchyme has a similar morphology and expression profile to fin mesenchyme of the major median fin lobe.

Fig. 1: A non-PM-derived median fin fold.
figure 1

a, Larval 4 dpf zebrafish possess a median PAFF (yellow arrowhead) in addition to the caudal median fin fold (cyan arrowhead). b, Confocal image of a 3 dpf Tg(tbx16l:GAL4-VP16); Tg(UAS:Kaede) embryo with PM labelled by Kaede showing PM-derived mesenchyme in the caudal median fin fold (cyan outline) but not the PAFF (yellow outline). ce, Confocal images of pre-anal (c), ventral caudal (d) and pectoral (e) fins of the ET37 Enhancer Trap transgenic line indicating that PAFF contains morphologically comparable mesenchyme (indicated by arrowheads) to other larval fin folds. f, In situ hybridization of the fin mesenchyme marker fbln1 in both PAFF (yellow arrowhead) and caudal fin fold (cyan arrowhead) at 3 dpf. g,h, DsRed expression in mesenchyme of both pre-anal (g) and caudal (h) fin folds of the 5 dpf Tg(-5.2lyve1b:DsRed) transgenic line. i,j, Immunostaining for collagen II in 8 dpf frf mutants (j) shows loss of fibril organization compared with WT (i). Scale bars, 200 µm (a); 100 µm (b); 20 µm (c,e); 50 µm (f,g,j).

Few functions of fin mesenchyme cells are defined. The zebrafish frilly fin (frf) mutants display ruffling of the caudal larval fin fold due to mutations in bone morphogenetic protein 1a (bmp1a), which is expressed in fin mesenchyme20, including in the PAFF (Extended Data Fig. 1j). The overall morphology of the PAFF also displays ruffling in frf mutants (Fig. 1i,j). Further, immunostaining of collagen II revealed ordered parallel collagen II fibres in all median fins of the wild type (WT), while these fibres were disorganized in both the caudal median fin folds and the PAFF of frf mutants (Fig. 1i,j), indicating that Bmp1a in PAFF mesenchyme is also required for maturation of collagen. Collectively, these results indicate that mesenchymal cells of the PAFF show functional overlap with those of the caudal median fin fold yet have a distinct developmental origin.

The transcription factor Hand2 is expressed in several LPM progenitors, including cardiac, pharyngeal, mesothelial and pectoral fin progenitors21,22. Upon examining the TgBAC(hand2:EGFP) transgenic line that accurately recapitulates endogenous hand2 gene expression23, we observed the expected enhanced green fluorescent protein (eGFP) expression in larval pectoral fins at 2–3 dpf (Fig. 2a,b). Although we observed no TgBAC(hand2:EGFP) expression in the major unpaired larval fin lobe, the PAFF mesenchyme was strongly eGFP positive, suggesting an LPM origin (Fig. 2a,b and Extended Data Fig. 2a,b). Additionally, in situ hybridization at 3 and 5 dpf indicated that the PAFF mesenchyme, but no other median fin fold, expressed hand2 (Fig. 2c,d and Extended Data Fig. 2c,d). If the LPM uniquely contributes to the PAFF, then we might expect that the PAFF, but no other median fin fold, would be affected in an LPM mutant. The zebrafish hand2 mutant hands off (hans6) exhibits defects in LPM derivatives, including the heart, pectoral fins and mesothelium21,22. Consistent with an LPM origin, the fin height of PAFFs in hans6 mutant larvae was significantly reduced compared with WT at 3 and 5 dpf, whilst the ventral section of the major median fin lobe was unaffected (Extended Data Fig. 3a,b,g,h,m). We observed similar results with hand2 antisense morpholino (MO)-based knockdown (Extended Data Fig. 3c–f,n). hand2 knockdown in the ET37 line severely reduced the number of eGFP-positive mesenchymal cells in the PAFF at 3 and 5 dpf compared with WT, whilst the mesenchyme of the ventral caudal median fin fold was unaffected (Extended Data Fig. 3i–l,o). Transplantation of hand2 MO; ET37 mutant cells into WT suggested that the loss of Hand2 reduced clone size and altered morphology and migration of mesenchyme cells autonomously (Extended Data Fig. 4). Together, these observations are consistent with an LPM origin of PAFF mesenchyme.

Fig. 2: The PAFF is an LPM-derived median fin fold.
figure 2

a,b, Confocal images of Tg(hand2:EGFP) embryos at 2 dpf (a) and 3 dpf (b) showing eGFP labelling of the mesenchyme of the pectoral (green outline and arrowheads) and PAFFs (yellow outline and arrowheads, and magnified in inset) but not the caudal fin fold (cyan outline). c,d, In situ hybridization of hand2 at 3 dpf shows fin expression of hand2 only in the PAFF (yellow arrowheads (c), and higher magnification with Nomarski optics indicates expression in the mesenchyme (d). e, Schematic of the LPM lineage tracing transgenes. f, Lineage tracing of LPM using transgenics depicted in (e) following 4-OHT treatment and heat shock before imaging shows that PAFF mesenchyme is derived from the LPM (yellow arrowhead and magnified in inset). g,h, Ventral (g) and lateral (h) confocal images of the drl:H2B-Dendra2 transgenic line at the 10-somite stage (10 ss) (g) and 48 hpf (h) following ultra-violet laser photoconversion in the region of the LPM outlined in (g). h, Photoconverted PAFF mesenchyme is indicated by yellow arrowheads. Scale bars, 100 µm (a,c,f); 50 µm (a (inset),f (inset),g,h); 200 µm (b); 20 µm (d).

To confirm that this expression of hand2 indicates an LPM origin of the PAFF rather than de novo expression, we permanently labelled the LPM in a mosaic fashion using a Tg(drl:creERT2; hsp70l:Switch) transgenic combination24 (Fig. 2e). During gastrulation and early somitogenesis, drl:creERT2 is expressed in LPM-primed mesoderm with increasing selectivity to the LPM, suitable for lineage labelling of this mesodermal lineage using 4-OH-tamoxifen (4-OHT) induction and loxP reporters24. Consistent with an LPM origin of paired appendages, we first documented that this LPM lineage tracing approach labels cells of the paired fins, in particular the larval pectoral fins and pelvic fins. We found lineage labelling in the endoskeletal disc and mesenchyme of 4.5 dpf pectoral fins and also, the intraray fibroblasts and Zns5-positive osteoblasts of the adult pelvic fins (Extended Data Fig. 5a–d). In addition, we observed LPM lineage labelling of the PAFF mesenchyme at 3 and 5 dpf, whilst the labelling in the caudal fin fold was limited to myeloid cells, which are also LPM derived (Fig. 2f and Extended Data Fig. 5e–g). These data further support the contribution of the LPM to the PAFF mesenchyme but not to other median fin folds. We next used drl-driven expression of the Dendra2 green-to-red photoconvertible fluorophore to localize the precise LPM origin of PAFF mesenchyme. During early to mid-somitogenesis (8–10-somite stage (ss)), drl:H2B-Dendra2 is expressed in the nuclei of the LPM (Extended Data Fig. 6a,b). Photoconversion of posterior-most LPM at this stage, using ultra-violet laser illumination, resulted in selective Dendra2-red labelling of this field of LPM (Fig. 2g and Extended Data Fig. 6c,d). These cells were then traced to the migrating PAFF mesenchyme at 40 and 48 hpf (n = 4) (Fig. 2h and Extended Data Fig. 6e–j,q–t), whilst unconverted control cells did not show any Dendra2-red PAFF labelling (Extended Data Fig. 6k–p,u–x). This confirmed PAFF mesenchyme originates from the LPM, with significant contribution from the posterior-most LPM at early segmentation stages.

To investigate whether an LPM-seeded median PAFF is a zebrafish apomorphy or if it is a more ancestral feature shared with other vertebrates, we examined the larvae of other taxa for the presence of a PAFF and used hand2 in situ hybridization as a proxy marker of an LPM origin of constituent mesenchymal cells. Medaka (Oryzias latipes) larvae have a markedly smaller PAFF that possesses only a sparse number of mesenchymal cells as detected by Nomarski imaging (Fig. 3a,b). These mesenchymal cells have cell extensions projecting distally and were mostly proximal in the fin where the interstitial space is thickest (Fig. 3b). Accordingly, medaka hand2 was expressed proximally in a punctate pattern in PAFFs, consistent with mesenchymal expression, and was not expressed in other median fin folds (Fig. 3c and Extended Data Fig. 7a–c). To confirm this, we expressed eGFP in early medaka LPM by injection of a –6.35drl:EGFP construct. We saw expression in mesenchymal cells in the PAFF transiently and also, in stable transgenic embryos (eight PAFF mesenchyme cells seen in four stage 36 Tg(-6.35drl:EGFP) transgenic medaka embryos) (Extended Data Fig. 7d,e). In addition, we used 1,1′-dioctadecyl-3,3,3′,3′-tetramethylindocarbocyanine perchlorate (DiI) lipophilic dye labelling to label the posterior LPM territory at stage 20 (four-somite stage). Consistent with our positional mapping of PAFF-seeding mesenchyme in zebrafish, posterior LPM injection of DiI consistently labelled mesenchyme in the medaka PAFF (total of 27 cells in nine of nine labelled embryos) (Extended Data Fig. 7f–i). A basal actinopterygian, the American paddlefish (Polyodon spathula), also forms a transient larval PAFF8; we identified the expression of P. spathula hand2 in PAFF mesenchymal cells between stages 36 and 39, but hand2 expression was notably absent from the caudal median fin fold (Fig. 3d,e and Extended Data Fig. 7j–l). PAFF hand2 mesenchyme expression persisted until PAFF regression (around stages 45 and 46). From stage 39, we observed hand2 expression in the core of the nascent pelvic fins (Extended Data Fig. 7k,l). We conclude that a larval PAFF with an LPM mesenchyme is ancestral for actinopterygians. To establish if an LPM contribution to median fins occurred before the origin of paired fins, we examined the larvae of a jawless vertebrate, the sea lamprey (Petromyzon marinus). Lampreys also possess a small transient larval PAFF25, within which strong, specific expression of the lamprey hand2 orthologue, HandA, was detected (Fig. 3f,g), although there was evidence of fainter HandA expression in the dorsal anterior fin. Finally, both the embryos of the sarcopterygian lungfish26 and amphibian tadpoles (e.g., Xenopus laevis27, Xenopus tropicalis and axolotls15) also possess a small transient PAFF (Fig. 3h). Fluorescence in situ hybridization demonstrated individual hand2-positive mesenchymal cells invading this fin in X. tropicalis but not the major median fin lobe at stage 42 (Fig. 3h–j). We confirmed this LPM contribution by injecting –6.35drl:EGFP into X. laevis embryos. X. laevis has a larger PAFF than X. tropicalis, and we observed extensive transient eGFP labelling in the PAFF compared with the caudal fin fold (Extended Data Fig. 7m–o). Thus, we show an LPM origin for PAFF mesenchyme in the larvae of representatives of major extant vertebrate linages: cyclostomes, actinopterygians and sarcopterygians.

Fig. 3: PAFF mesenchyme expression of hand2 is conserved across vertebrates.
figure 3

a,b, Nomarski images of 9 dpf medaka showing PAFF (a) with dispersed mesenchymal cells (yellow arrowheads) (b). c, In situ hybridization of medaka at stage 39 showing hand2 expression in pre-anal fin mesenchyme (yellow arrowheads). d,e, In situ hybridization of hand2 in stage 36 paddlefish embryos shown laterally (d) or in transverse section (e). hand2-positive PAFF fin mesenchyme is indicated by yellow arrowheads. f,g, HandA in situ hybridization of stage E29 lamprey (P. marinus) embryos shown laterally (f) or in transverse section (g). Lamprey show strong expression of HandA in a fin anterior to the anus (yellow arrowhead in f) corresponding to cells in the interior of the fin (g). The section location of (g) is indicated by the dashed line in (f). hj, Chromogenic (h) or fluorescent (i,j) in situ hybridization of hand2 in stage 42 X. tropicalis embryos shown laterally (h) or in transverse section (i,j). Fluorescent image (j) is overlayed on the Nomarski image (i). The small PAFF in Xenopus contains sparse hand2-positive fin mesenchyme (yellow arrowheads). St., stage. Scale bars, 100 µm (a,d,h); 10 µm (b); 20 µm (c); 50 µm (eg,i).

Given the LPM origin of the median PAFF, we considered that it may have importance in the transition from PM-derived median fins to LPM-derived paired fins. We tested if this LPM median fin fold could be duplicated into paired LPM-derived lateral fin folds. Zebrafish larvae mutant for the bone morphogenetic protein (BMP) antagonist chordin develop ventral caudal fin fold duplications, although whether the PAFF is duplicated in these mutants has not been reported28. Injection of a low dose of chrd MO into zebrafish recapitulated various ventralized phenotypes, which included individuals with duplicated or multiple PAFFs (Fig. 4a,b,f and Extended Data Fig. 8a,b). We visualized these PAFF phenotypes by chrd MO injection into the ET37 transgenic line, which demonstrated that each fin fold of duplicated PAFFs contained mesenchyme (Fig. 4c,d). Lineage tracing using the Tg(drl:creERT2; hsp70l:Switch) transgenic combination injected with chrd MO demonstrated that the mesenchyme cells of the duplicated PAFFs are indeed derived from the LPM (Fig. 4e). By generating chrd morphants in the Tg(hand2:EGFP) line and then imaging by light-sheet microscopy, we generated three-dimensional reconstructions documenting duplicated PAFFs along the yolk extension, all of which harboured eGFP-positive mesenchymal cells, further demonstrating that the mesenchyme of these duplicate fin folds was LPM derived (Fig. 4g–i, Extended Data Fig. 8c–j and Supplementary Video 1). Of note is the generation of multiple parallel fin folds in individual embryos following chrd MO injection (Fig. 4f). These observations indicate that bifurcation of the LPM-seeded PAFF readily arises from modulating ventral BMP signalling, such as by reducing the dose of the dorsal inhibitor Chordin.

Fig. 4: Duplication of the PAFF into paired fin folds.
figure 4

a,b, Lateral (a) and ventral (b) Nomarski images of PAFFs of 5 dpf (a) and 4 dpf (b) embryos injected with MO targeting chordin, resulting in duplication of PAFF (yellow arrowheads). c,d, Confocal micrographs, imaged ventrally, of PAFFs in 4 dpf ET37 transgenic larvae uninjected (c) or injected with a chrd MO (d). PAFFs are indicated with yellow lines. d, Note the duplicated anal openings following chrd MO injection. e, Ventral confocal image of chrd MO duplicated PAFFs of the transgenic line shown above. Hydroxytamoxifen treatment at the 12-somite stage and heat shock before imaging show that mesenchyme of duplicated PAFFs is derived from the LPM (yellow arrowheads). fi, Light-sheet (f) and confocal (gi) images of Tg(hand2:EGFP) larvae at 8 dpf (f) and 6 dpf (gi). Orthogonal display through the xz plane (f,g) shows that multiple PAFFs can form and that duplicated PAFFs contain eGFP-positive mesenchyme (gi). Lateral views of left (h) and right (i) duplicated PAFFs of sample in g are given. j,k, Lateral low- (j) and high-power (k) Nomarski images of the PAFF of the Ranchu goldfish at 6 dpf. The multiple PAFFs (j) and individual mesenchyme cells (k) are indicated by yellow arrowheads. Duplicated caudal fin folds are indicated by cyan arrowheads (j). ln, Lateral (l,m) and transverse (n) views of pre-anal (l,n) and caudal (m) fin folds of 7 dpf Ranchu larvae stained by in situ hybridization for hand2, where hand2-positive PAFF mesenchyme is indicated by yellow arrowheads. Absence of hand2 in the caudal fin fold is indicated by the cyan arrowhead (m). Scale bars, 100 µm (a,e,m); 20 µm (b,fh,n); 50 µm (d,k); 200 µm (j).

To determine if the generation of multiple PAFFs could have evolved spontaneously as part of natural variation, we examined the twin-tail goldfish strain, Ranchu, which has been shown to display bifurcated fin folds including PAFFs due to a loss-of-function mutation in a chordin paralogue (chdAE127X)29,30,31. The bifurcated PAFFs and caudal fin folds of larval Ranchu appeared similar to those of zebrafish larvae injected with low doses of chrd MO (Fig. 4j and Extended Data Fig. 8k,l). These PAFFs were all populated by mesenchymal cells (Fig. 4k). Using hand2 in situ hybridization as a proxy of LPM lineage to infer the origin of the Ranchu PAFF mesenchyme, we observed that the core of both duplicated PAFFs expressed hand2, whilst the caudal fin fold did not (Fig. 4l–n and Extended Data Fig. 8m,n). This suggests that, as in the zebrafish PAFF, the bifurcated Ranchu PAFFs are also LPM derived. Notably, in addition to those displaying simple PAFF duplication, some individuals had three or more parallel PAFFs (Fig. 4j and Extended Data Fig. 8n). Thus, we conclude that LPM-derived paired fin folds that can be readily generated in zebrafish larvae have also arisen spontaneously in twin-tail goldfish; thus, they represent a viable morphological innovation. Notably, duplicated LPM-derived PAFFs were situated in ventrolateral locations between the future pectoral and pelvic fin domains, overlying the proposed competence stripes of appendage formation in gnathostomes32.

Combining several models and techniques, we here have identified a larval median fin with a mesenchyme core derived from LPM and propose it as an intermediate between PM-derived median fins and LPM-derived paired fins. While apparently conserved from cyclostomes to amphibia, most extant chondrichthyan embryos do not appear to have a discernible PAFF. We used micro-computed tomography (microCT) to examine prehatching stages of the elasmobranch Epaulette shark Hemiscyllium ocellatum, which did not show the presence of a clear pre-anal fin (Extended Data Fig. 9a–i). Although this pattern appears to support a loss of the PAFF somewhere in the chondrichthyan lineage, we cannot rule out the possibility that a PAFF arose independently in cyclostomes and Osteichthyes. It is interesting to note that embryos and adults of the frilled shark, Chlamydoselachus, do show bifurcated tropeic folds in the ventral midline (Extended Data Fig. 9j–m), structures previously invoked as supporting the fin fold hypothesis33.

PAFFs are mostly transient larval structures that generally lack a mineralized skeleton, which may explain their poor documentation in the fossil record. Although a true PAFF does not persist into adulthood in most species, it is seen in hagfish adults, where unlike the caudal median fin, it does not possess cartilage rays34. In the fossil record, a pre-anal fin is seen in some stem vertebrate fossils, including Haikouella and Haikouichthys, while the pre-anal fin of Kerreralepis shows well-developed plates35,36. Zebrafish larval fin mesenchyme is known to persist and contribute to the lepidotrichia of adult fins18, and LPM-derived dermal fibroblasts form cartilage during axolotl limb regeneration37. These data suggest the potential of the PAFF mesenchyme to generate skeletal outcomes.

Spontaneous duplication in twin-tail goldfish species indicates that paired LPM-derived PAFFs could have readily arisen during evolution. In Ranchu, we frequently observed multiple PAFFs, permitting retention of a median PAFF and divergence of duplicates into paired fins. Although there is no evidence of lateral fin folds present in extant vertebrates, adult specimens of the hagfish species Neomyxine biniplicata possess anterior lateral paired folds that terminate close to the pre-anal fin38, resembling partial duplications of the pre-anal fin, although their relevance to paired fin evolution is disputed39. In the fossil record, there is evidence that both mineralized and unmineralized lateral paired fin folds were common in anaspids, although homology of anapsid and gnathostome paired fins is highly contentious, as is their relevance to paired fin evolution and the lateral fin fold hypothesis1,11. Pharyngolepis, Cowielepis and Euphanerops display pre-anal ventrolateral paired ribbon structures or triangular fins with radials, while in Jamoytius, the ribbons lacked mineralized structures12,40,41. The galeaspid, Tujiaaspis, has been recently described bearing skeletal ventrolateral fins composed of skeletal units42. Subsequent regionalization of these adult paired elongate fins through anterior restriction to the pectoral fin region is proposed and exemplified by Pharyngolepis and Rhyncholepis11,43.

Our work gives weight to a model for paired fin evolution through co-option of a larval median fin programme to the LPM followed by fin duplication and subsequent regionalization to pectoral and pelvic fins. We present one possible model for how the PAFF may have led to the generation of LPM-derived paired fins (Fig. 5). The PAFF may have originated as a small ectoderm-only fin fold (as seen in amphioxus larvae44) with an LPM contribution evolving subsequently upon alterations in LPM topology, such as persistence of a somatopleure and/or a lateral mesodermal divide45,46. Similar LPM tissue contexts may have then led to PAFF elongation and following duplication, paired fin regionalization. As the PAFF possesses characteristics of both unpaired and paired fins, the PAFF may represent a novel evolutionary module or at least demonstrate components of the developmental mechanisms that contributed to the emergence of paired appendages.

Fig. 5: Hypothesis of the elaboration of the PAFF to paired fins.
figure 5

Simplified evolutionary scenario of vertebrates showing the presence of a PAFF and subsequent modifications leading to paired fins. Dashed lines and dagger symbols indicate extinct lineages, and solid lines indicate extant lineages. PM-derived fins and fin folds are in cyan, while LPM-derived fins are in pink. Larval PAFF is hatched. Black arrows indicate the position of the anus.
